Carbonized Fiber Packing with Graphite

Carbonized Fiber Packing with Graphite

Kaxite carbonized fiber packing with graphite is braided from carbonized PAN fiber impregnated with PTFE dispersion containing graphite particles. The PTFE + graphite combination gives the packing excellent self-lubrication — the specific advantage over the plain Carbonized Fiber Packing with PTFE, which relies on PTFE alone. Rated rotary 20 bar at 25 m/s, reciprocating 100 bar, static 200 bar, -50°C to +280°C, pH 2–12, density 1.3 g/cm³. Designed for weak acids and alkalis and media with a few solid particles, in both dynamic and static service, in centrifugal pumps, plunger pumps, mixers and valves. Hot water up to 160°C without cooling, up to 207°C with cooling — particularly for hot water, condensate and main coolant pumps. Supplied in 5–10 kg coils; braided ring form available.
Carbonized Fiber Packing with PTFE

Carbonized Fiber Packing with PTFE

Kaxite carbonized fiber packing with PTFE is braided from oxidized polyacrylonitrile (pre-oxidized PAN) fiber impregnated with PTFE, silicone-oil-free. This is not the same material as a fully carbonized carbon fiber packing: the pre-oxidized fiber is not brittle, tolerates high peripheral speeds (25 m/s), and is suitable for food industry service. The PTFE impregnation provides self-lubrication, so the braid does not damage shafts and achieves long service life. Rated rotary 20 bar at 25 m/s, reciprocating 100 bar, static 200 bar, -50°C to +280°C, pH 2–12, density 1.3 g/cm³. Hot water up to 160°C without cooling, up to 207°C with cooling — particularly for hot water, condensate and main coolant pumps. Supplied in 5–10 kg coils; ring form available. For the graphite-marking-sensitive process, compare the Carbonized Fiber Packing with Graphite grade on the same base fiber.
Carbon Fiber Packing

Carbon Fiber Packing

Kaxite Carbon Fiber Packing is braided from strong carbon continuous yarns after softening, impregnated with proprietary lubricants and graphite particles that fill voids, act as a break-in lubricant and block leakage. It is a continuous carbon yarn product — not the pre-oxidized PAN base used in the site's Carbonized Fiber Packing with PTFE — and the continuous carbon yarn construction is what drives the higher -50°C to +650°C temperature ceiling. Rated rotary 25 bar at 20 m/s, reciprocating 100 bar, static 200 bar, pH 1–13, density 1.4 g/cm³. Specified for steam turbines, motor-actuated high-temperature valves, power stations, refineries, boiler plants. Can be used stand-alone or combined with graphite rings as anti-extrusion rings; when combined with pure graphite rings it forms a perfect seal for dry-running equipment such as ventilators and fans. Seats quickly with minimal break-in adjustment. Supplied in 5–10 kg coils; ring form available.
